12 Leads Ecg Machine Touch Screen 3 Channel Professional EKG Device For Hospital

Name: 12 Leads Ecg Machine Touch Screen 3 Channel Professional EKG Device For Hospital
Brand: Rainbow
Price: 1 USD

Buy cheap 12 Leads Ecg Machine Touch Screen 3 Channel Professional EKG Device For Hospital product

Brand Name : Rainbow

Model Number : ECG-8203

Certification : ISO13485

Place of Origin : China

MOQ : 1 unit

Price : US $330-388/unit

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 30000units/year

Delivery Time : Within 3 days

Packaging Details : Anti-collision film+ Carton box Carton box dimension: 32*25*17cm Gross weight: 2.8kg

Power Source : Electric

Warranty : 1 year

After-sale Service : Online technical support

Material : Plastic

Quality Certification : ce

Instrument Classification : Class II

Type : Medical device ECG

Display : 7 inch colar LCD touch screen

Sale Points : Support SD card, USB disk

Lead : 12 leads

Contact Now

ECG Machine 12 Leads Ecg Touch Screen 3 Channel Professional EKG Device For Hospital

Features
1.Digital signal processor for effective inhibition of baseline drift, AC interference filter, MG interference filter and the heart rate, to guarantee the authenticity and dependability
2.Auto-regulation of baseline drift can effectively inhibit baseline drift, optimizing the printing position to achieve high-quality ECG
3.Have regular automatically measuring and analyzing function for ECG parameters to lessen doctor's load.
4.With a high -resolution thermal printer to print out ECG trace, describing the trace clear and accurate, annotation as well as related parameters for diagnostic reference.
5.Roll recording paper for ECG is 80mm in width, simultaneous 12 lead acquisitions and 3 lead live record, high affectivity of ECG examination, good effect and economic utility.
6.Function of rhythm lead for observing abnormal ECG trace & heart rate.
7.Supported by AC/Rechargeable battery for continuous examination whenever necessary. For Battery operation.

8.ECG is equipped with a battery charger and a system for battery capacity management and protection
Safety level for ECG corresponds to Type CF, Class I according to the IC60601-1 criterion. The amplifier is floating input circuit which can examine human cordis directly with safety and reliability

Main technical specification

Items	specification
Lead	standard 12 leads
lead acquisition	synchronously 12 leads
Input circuit	Floating; Protection circuit against Defibrillator effect
Input Impedance	≥50MΩ
Input circuit current	≤0.0.05 A
Record mode	Automatic: 3CH×4+1R, 3CH×4, 3СН×2+2CH×3,3CH×2+2CH×3+1R,6CHX2; Manual: 3CH, 2CH, 3CH+1R, 2CH+1R; Rhythm: Any lead selectable.
Filter	EMG Filter: 25 Hz / 30 Hz/ 40H2/75 Hz/ 100 Hz / 150Hz DFT Filter: 0.05 Hz/ 0.15 Hz AC Filter: 50 Hz/ 60Hz
CMRR	>100dB
Patient current leakage	<10 A
Input Circuit Current	<0.05 A
Frequency Response	0.05Hz~150Hz (-3dB)
Sensitivity	2.5mm/m V, 5 mm/m V, 10 mm/m V, 20 mm/mV
Anti-baseline Drift	Automatic
Time constant	≥3.2s
Noise level	<15 Vpp
Paper speed	12.5 mm/s, 25 mm/s, 50 mm/s
Recording mode	Thermal printing system
Paper specification	80mmx20m paper roll
LCD display	7''graphic LCD
Safety classification	IEC60601-1 class I, type CF
Power supply	AC: 100~240V, 50/60Hz, 30VA~100VA
	DC: 14.8V/2200mAh, built-in lithium battery
Fuse	AC220V=10% 2*Ф5×20mm, T2A/250V AC time lag
	AC110V+10% 2*Ф5×20mm.T4A/250V AC time lag

Accessories

Item	Description	Quantity
1	Patient Cable	1
2	Limb Electrode	4pcs/set
3	Chest Electrode	6pcs/set
4	Three plugged power cable	1
5	Grounding Cable	1
6	Paper Shaft	1
7	Thermal Recording Paper	1

12 Leads Ecg Machine Touch Screen 3 Channel Professional EKG Device For Hospital
