Clinical Analytical Electrocardiogram Medical Ecg Ekg Machine 6 Channel 7 Inch

Brand Name : RAINBOW

Model Number : ECG-8206

Certification : ISO13485, FSC

Place of Origin : Hunan, China

MOQ : 1 unit

Price : US $330-399/unit

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 30000units/year

Delivery Time : Within 3 days

Packaging Details : Anti-collision film+ Carton box Packing size: 32*25*20cm Gross weight: 3 kg

Product name : Electrocardiogram machine

Power Source : Electricity/ Built-in Battery

Shelf Life : 2 years

Packing : Carton box

Port : Guangzhou/Shanghai/Shenzhen

Display : 7" touch screen

Contact Now

Clinical Analytical Instruments 7 inch medical ecg ekg 6-channel electrocardiogram machine



Sale points

1. Full screen display of 12 channel ECG waveforms, 7 inch touch screen

2. Digital 6 channel automatic measurement, analysis and diagnosis with report printing

3. Light-weight,exquisite and easy to carry

4. Multiple operation modes: manual, automatic, rhythm, physical examination

5. Support high-capacity SD memory,USB disk real-time storage of waveforms and diagnostic analysis

Technical Specification



Items
specification
Features
7 "display,

touch screen

Support Ecg analysis capabilities
Lead


standard 12 leads
lead acquisition
synchronously 12 leads
Input circuit
Floating; Protection circuit against Defibrillator effect
Input Impedance
≥50MΩ
Input circuit current
≤0.0.05μA
Record mode
Automatic: 3CH×4+1R, 3CH×4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2;
Manual: 3CH, 2CH, 3CH+1R, 2CH+1R;
Rhythm: Any lead selectable.
Filter
EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz
DFT Filter: 0.05 Hz/ 0.15 Hz
AC Filter: 50 Hz / 60Hz
CMRR
>100dB
Patient current leakage
<10μA
Input Circuit Current
<0.05µA
Frequency Response
0.05Hz~150Hz (-3dB)
Sensitivity
2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV
Anti-baseline Drift
Automatic
Time constant
≥3.2s
Noise level
<15μVp-p
Paper speed
12.5 mm/s, 25 mm/s, 50 mm/s
Recording mode
Thermal printing system
Paper specification
ECG-8203: 80mmx20m paper roll
ECG-8206: 110mmx20m paper roll



Standard
Patient cable
1set
Limb electrode
4sets
Chest elelctrodes
6sets
Gounding cable
1set
Paper axis
1set
Thermal paper
1set
Fuse
2sets
power cord
1set
AC Adaptor
1set

Clinical Analytical Electrocardiogram Medical Ecg Ekg Machine 6 Channel 7 Inch

Clinical Analytical Electrocardiogram Medical Ecg Ekg Machine 6 Channel 7 Inch

Clinical Analytical Electrocardiogram Medical Ecg Ekg Machine 6 Channel 7 Inch

Company Profile

Hunan Rainbow Technology Limited Corporation is the pioneer manufacturer of high technology medical equipment, meantime, it is also the leader of domestic monitor innovation. Since the foundation of 1997, company always dedicated on the research and production of clinical monitor. Products cover fetal monitor, maternal-fetal monitor, multi-parameter monitor, central monitoring network system and so on, with cost-effective price and high quality! Company stick to customer demand orientation, and pursue the goal of customer satisfaction as service principle. All the equipments have our promise of two year replacement and life time warranty. The registered capital of company is 10 million RMB. The capacity of annual production mount up to 10000 sets. The "Rainbow" brand treatment monitor of our company have been rated as Hunan famous brand. Company stick to small profit but quick return and integrity management principle. Popular products (multi-parameter monitor) occupied 50% above of domestic market share. Heading for a goal of more professional, large scale, and more international.
